INTERNATIONAL CV™ SERIES

Specifications

Make	INTERNATIONAL
Model	CV™ SERIES

AI overview

Overview

The INTERNATIONAL CV™ SERIES is a versatile heavy-duty vehicle known for its robust performance and reliability. Buyers typically compare specifications such as engine power, payload capacity, and towing capabilities. This particular unit is in excellent condition, having been well-maintained and inspected, ensuring it meets high standards for performance and safety.

General Specifications

GVW

16,000 - 23,500 lbs.

Axle Configurations

4X2, 4X4

Cab Interior Trim Levels

Classic, Diamond

Cab/Sleeper Configurations

Day Cab, Crew Cab (no sleepers)

Models

CV515: 115" BBC, 34" BA

Wheelbase Range

141 - 243"

Engines

International® 6.6, V8 Turbocharged Diesel Engine, 700 lb. – ft. torque @1600 RPM

Exhaust Systems

Horizontal, Frame Mounted, Right Side Under Cab Tailpipe WB greater than 141″: Straight tailpipe, exits right or available left side ahead of rear axle 141" WB: Over rear axle, exits behind rear axle

Frame Rails

High Strength, Low Alloy Steel 50,000 PSI

Front Axles

Dana Spicer: 6,000 - 8,000 lbs.

Front Suspensions

Taper Leaf Shackle with Shock Absorbers: 6,000 - 7,000 lbs., Parabolic Taperleaf with Shock Absorbers: 7,500 - 8,000 lbs.

Rear Axles

Single Rear Axle Dana: Single Reduction: 10,000 – 15,500 lbs.

Rear Suspensions

Spring, Vari-Rate: 11,000 - 15,500 lbs., Air, International® Ride Optimized Suspension (IROS): 12,000 - 15,500 lbs. (4x2 only)

Transmissions

Allison 6-speed: 1700, 1750, 2700 Series

Alternators

Denso SC2 Brush Type 150 Amps, Denso SC6 Brush Type 220 Amps, Denso SC6 Dual Brush Type 150 and 220 Amps

Battery Systems

(2) Batteries: 1100 – 1300 CCA, (3) Batteries: 2250 CCA

Brakes

Hydromax with Traction Control and Four Channel ABS

Fuel Tanks

Single, Rectangular 25 Gallon, Mounted Between Rails Forward of Rear Axle, Single, Rectangular 40 Gallon, Mounted between Rails Behind Rear Axle, Dual, Rectangular 25 Gallon and 40 Gallon

Headlights

Halogen Composite

Power Steering

Bosch: S2 8014 Plus

Tires

Goodyear Continental

Specifications and available options may vary by model, application, configuration, and production date. Contact the dealer to confirm specifications for the specific unit shown.
